Heat & Cold Resistant Brass Cable Glands
? Thread Type: Metric and PG.? Material Data : Standard in Stainless Steel A2 ( DIN 1.4305 / AISI 303 ) for A.C.F parts ; Contact us for ordering Stainless Steel A4 ( 1.4404 / AISI 316L ).Special he...
? Thread Type: Metric and PG.
? Material Data : Standard in Stainless Steel A2 ( DIN 1.4305 / AISI 303 ) for A.C.F parts ; Contact us for ordering Stainless Steel A4 ( 1.4404 / AISI 316L ).
Special heat resistance polyamide for E part ; Special heat & weather resistance rubbers for B.D parts.
Acid / Alkali proof & Weather-resistant rubbers for B.D parts. ( NBR rubber is optional for oil-resistance applications )
? IP Protection :IP68 - 5 bar.
? Working Temp. :- 40 °C to 150 °C ( - 40 °F to 302 °F ) ; intermittent to approx. 180 °C ( 356 °F ).
? Application :With the higher requirements for stability & severe temperature resista ce under tough conditions, the higher strength & rustproof stainless steel with the special heat & cold resistant sealing rubber { well known for ts excellent - 50 °C ( - 58 °F ) to 200 °C ( 392 °F ) working temperature range } are adopted for building this tough cable gland to offering the best durability in severe weather, flame, chemical and high impact environments. In addition, the gland with Yongcun’s perfect clamping design provides the outstanding strain relief force & watertight performance over the entire cable range to be the unmatched long life cable entry system for outdoor / indoor applications in the specific requirements.
